Silicon SPDT Switch, Reflective, 9 kHz to 44 GHz Features: Ultrawideband frequency range: 9 kHz to 44 GHz Reflective design Low insertion loss with impedance match 0.9 dB typical to 18 GHz 1.4 dB typical to 40 GHz 1.6 dB typical to 44 GHz Low insertion loss without impedance match 0.9 dB typical to 18 GHz 1.7 dB typical to 40 GHz 2.2 dB typical to 44 GHz High input linearity P1dB: 27.5 dBm typical IP3: 50 dBm typical High RF input power handling Through path: 27 dBm Hot switching: 27 dBm No low frequency spurious RF settling time (50% VCTL to 0.1 dB final RF output): 3.4 μs 12-terminal, 2.25 mm × 2.25 mm LGA package Pin compatible with the ADRF5024 fast switching version

Silicon SPDT Switch, Nonreflective, 100 MHz to 44 GHz Features: Ultrawideband frequency range: 100 MHz to 44 GHz Nonreflective design Low insertion loss: 1.2 dB to 18 GHz 1.7 dB to 26 GHz 2.4 dB to 40 GHz 3.8 dB to 44 GHz High isolation 55 dB to 18 GHz 53 dB to 26 GHz 50 dB to 40 GHz 45 dB to 44 GHz High input linearity P1dB: 27 dBm typical IP3: 53 dBm typical High power handling 24 dBm insertion loss path 24 dBm isolation path All off state control No low frequency spurious signals 0.1 dB RF settling time: 40 ns typical 20-terminal, 3 mm × 3 mm LGA package Pin compatible with ADRF5027, low frequency cutoff versionADRF5026-EP supports defense and aerospace applications (AQEC standard) Download ADRF5026-EP data sheet (pdf) Supports defense and aerospace applications (AQEC standard) Military temperature range (−55°C to +105°C) Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on request V62/21601 DSCC Drawing Number

Silicon SPDT Switch, Reflective, 35 GHz to 44 GHz Features:Reflective design Low insertion loss: 1.8 dB at 44 GHz High isolation: 28 dB at 44 GHz High input linearity 0.1 dB power compression (P0.1dB): 37 dBm Third-order intercept (IP3): 52 dBm High RF power handling: 28 dBm average 36 dBm peak Single supply operation: 3.3V Internal negative voltage generator (NVG) RF settling time (0.1 dB final RF output): 45 ns 20-terminal, 3 mm × 3 mm, land grid array package Pin compatible with the ADRF5300: 24 GHz - 32 GHz

0.5 dB LSB, 6-Bit, Silicon Digital Attenuator, 100 MHz to 40 GHz Features:Ultrawideband frequency range: 100 MHz to 40 GHz Attenuation range: 0.5 dB steps to 31.5 dB Low insertion loss with impedance match 2.1 dB up to 18 GHz 2.9 dB up to 26 GHz 4.8 dB up to 40 GHz Attenuation accuracy with impedance match ±(0.10 + 1.0% of attenuation state) up to 18 GHz ±(0.15 + 0.8% of attenuation state) up to 26 GHz ±(0.35 + 2.5% of attenuation state) up to 40 GHz Typical step error with impedance match ±0.18 dB up to 18 GHz ±0.23 dB up to 26 GHz ±0.51 dB up to 40 GHz High input linearity P0.1dB insertion loss state: 30 dBm P0.1dB other attenuation states: 27 dBm IP3: 50 dBm typical High RF input power handling: 27 dBm average, 30 dBm peak Tight distribution in relative phase No low frequency spurious signals SPI and parallel mode control, CMOS/LVTTL compatible RF settling time (0.1 dB of final RF output): 250 ns 24-terminal, 4 mm × 4 mm LGA package Pin compatible with ADRF5720, low frequency cutoff version

2 dB LSB, 4-Bit, Silicon Digital Attenuator, 100 MHz to 40 GHz Features: Ultrawideband frequency range: 100 MHz to 40 GHz Attenuation range: 2 dB steps to 30 dB Low insertion loss 1.7 dB to 18 GHz 2.2 dB to 26 GHz 3.5 dB to 40 GHz Attenuation accuracy ±(0.1 + 2.0%) of attenuation state up to 18 GHz ±(0.2 + 2.5%) of attenuation state up to 26 GHz ±(0.5 + 10.0%) of attenuation state up to 40 GHz High RF input power handling: 26 dBm average, 30 dBm peak Tight distribution in relative phase Typical step error ±0.15 dB to 18 GHz ±0.20 dB to 26 GHz ±0.60 dB to 40 GHz High input linearity P0.1dB insertion loss state: 30 dBm P0.1dB other attenuation states: 26 dBm IP3: 50 dBm typical No low frequency spurious signals SPI and parallel mode control, CMOS/LVTTL compatible RF amplitude settling time (0.1 dB of final RF output): 230 ns 2.5 mm × 2.5 mm, 16-terminal LGA package Pin compatible with ADRF5721, low frequency cutoff version

Dual Narrow/Wideband RF Transceiver Features: 2 2 highly integrated transceiver Frequency range of 30 MHz to 6000 MHz Transmitter and receiver bandwidth from 12 kHz to 40 MHz Two fully integrated, fractional-N, RF synthesizers LVDS and CMOS synchronous serial data interface options Low power monitor and sleep modes Multichip synchronization capabilities Fast frequency hopping Dynamic profile switching for dynamic data rates and sample rates Fully programmable via a 4-wire SPI 12 mm 12 mm, 196-ball CSP_BGA

Integrated Dual RF Receiver Features: Dual receivers Maximum Receiver BW: 200 MHz Fully integrated, fractional-N, RF synthesizers Fully integrated clock synthesizer Multichip phase synchronization for RF LO and baseband clocks JESD204B datapath interface Tuneable range: 75 MHz to 6000 MHz

Integrated Dual RF Tx, Rx, and Observation Rx Features: Dual transmitters Dual receivers Dual input shared observation receiver Maximum receiver bandwidth: 200 MHz Maximum tunable transmitter synthesis bandwidth: 450 MHz Maximum observation receiver bandwidth: 450 MHz Fully integrated fractional-N RF synthesizers Fully integrated clock synthesizer Multichip phase synchronization for RF LO and baseband clocks JESD204B datapath interface Tuning range (center frequency): 75 MHz to 6000 MHz

Integrated, Dual RF Transceiver with Observation Path Features: Dual differential Tx Dual differential Rx Observation receiver with 2 inputs Fully integrated, ultralow power DPD actuator and adaptation engine for PA linearization Sniffer receiver with 3 inputs Tunable range: 300 MHz to 6000 MHz Linearization signal BW to 40 MHz Tx synthesis BW to 250 MHz Rx BW: 8 MHz to 100 MHz Supports FDD and TDD operation Fully integrated independent fractional-N RF synthesizers for Tx, Rx, ORx, and clock generation JESD204B digital interface

Up to 1GHz SHARC+ DSP with 640KB L1, 1024KB Shared L2 SRAM, 120-lead LQFP_EP Features:SHARC+ Core infrastructure 800MHz (max) or 1GHz (max) Core clock frequency 640KB on-chip Level 1 (L1) SRAM memory (with parity) increases low latency performance 32-bit, 40-bit & 64-bit floating point support 32-bit fixed point Byte, short-word, word, long-word addressedMemory 1024KB on-chip Level 2 (L2) SRAM with ECC protection - eliminates need for external memory in many use cases Advanced Hardware Accelerators Enhanced FIR/IIR offload engines running at Core clock frequency for added processing power Security Crypto Engines with OTPPowerful DMA SystemInnovative Digital Audio Interface (DAI) includes: 8x Full SPORT interfaces w/TDM & I2S modes 2x S/PDIF Rx/Tx, 8 ASRC pairs 4x Precision Clock Generators 24 BuffersOther Peripheral Connectivity / Interfaces: 2x Quad SPI, 1x Octal SPI MLB 3-pin 4x I2C, 2x UARTs 6x General Purpose Timer, 1x General Purpose Counter 2x Watchdog Timers 2-ch 12bit Housekeeping ADCs 22 GPIO pins, 24 DAI pins Thermal SensorPackage 14mm x 14mm 120-lead LQFP_EAdditional Features Security and Protection Crypto hardware accelerators Fast secure boot with IP protection Enhanced FIR and IIR accelerators running up to 1 GHz AEC-Q100 qualified for automotive applications
