Low Cost, 300 MHz Rail-to-Rail Amplifier (Single with Disable) Features: Low cost Single (AD8061), dual (AD8062) Single with disable (AD8063) Low offset voltage: 6 mV High speed 300 MHz, −3 dB bandwidth (G = 1) 650 V/μs slew rate 8.5 nV/√Hz at 5 V 35 ns settling time to 0.1% with 1 V step Operates on 2.7 V to 8 V supplies Input voltage range = −0.2 V to +3.2 V with Vs = 5 V Excellent video specifications (RL = 150 Ω, G = 2) Gain flatness: 0.1 dB to 30 MHz 0.01% differential gain error 0.04° differential phase error 35 ns overload recovery Low power 6.8 mA/amplifier typical supply current 400 μA when disabled

Full Accurate 3 V/5 V 16-Bit VOUT nanoDAC Converter, Output Buffered, in a Sot 23 Features: Available in 8-lead SOT23 16 Bit Accurate, MAX 1 LSB INL including output buffer Low Glitch on Power-up Three power down functions available High speed serial interface with clock speeds up to 30 MHz Three power down modes available to the user

Software Selectable True Bipolar Input, 4-Channel, 12-Bit Plus Sign A/D Converter Features: 12-Bit plus sign SAR ADC True bipolar input ranges Software-selectable input ranges ± 10V, ± 5V, ± 2.5V, 0V to 10V 1 MSPS throughput rate 4 analog input channels with channel sequencer Single -ended, true differential, and Pseudo differential analog input capability High analog input impedance Low power: 21 mW Full power signal bandwidth: 22 MHz Internal 2.5 V reference High speed serial interface For more features please see data sheet

The HMC565 is a high dynamic range GaAs PHEMT MMIC Low Noise Amplifier (LNA) chip which operates from 6 to 20 GHz. The HMC565 features 22 dB of small signal gain, 2.3 dB of noise figure and has a consistent IP3 of 20 dBm across the operating band. This self-biased LNA is ideal for hybrid and MCM assemblies due to its compact size, wideband performance, single +3V supply operation, and DC blocked RF I/O’s. All data is measured with the chip in a 50 Ohm test fixture connected via two 0.025 mm (1 mil) diameter bondwires of minimal length 0.31 mm (12 mil).Applications Point-to-Point Radios  Point-to-Multi-Point Radios & VSAT  Test Equipment and Sensors  Military & Space

High Performance, SPI Digital Output, Angular Rate Sensor Features: Excellent null offset stability over temperature High vibration rejection over a wide frequency range 2000 g powered shock survivability SPI digital output with 16-bit data-word Low noise Continuous self-test Fail-safe functions Temperature sensor 3.3 V and 5 V operation −40°C to +105°C operation Small, low-profile industry standard SOIC package provides yaw rate (Z-axis) response Innovative ceramic vertical mount package (VMP) provides pitch and roll rate response Qualified for automotive applications

The ADP5070 is a dual high performance dc-to-dc regulator that generates independently regulated positive and negative rails.The input voltage range of 2.85 V to 15 V supports a wide variety of applications. The integrated main switch in both regulators enables generation of an adjustable positive output voltage up to +39 V and a negative output voltage down to −39 V below input voltage.The ADP5070 operates at a pin selected 1.2 MHz/2.4 MHz switching frequency. The ADP5070 can synchronize with an external oscillator from 1.0 MHz to 2.6 MHz to ease noise filtering in sensitive applications. Both regulators implement programmable slew rate control circuitry for the MOSFET driver stage to reduce electromagnetic interference (EMI).Flexible start-up sequencing is provided with the options of manual enable, simultaneous mode, positive supply first, and negative supply first.The ADP5070 includes a fixed internal or resistor programmable soft start timer to prevent inrush current at power-up. During shutdown, both regulators completely disconnect the loads from the input supply to provide a true shutdown.Other key safety features in the ADP5070 include overcurrent protection (OCP), overvoltage protection (OVP), thermal shutdown (TSD), and input undervoltage lockout (UVLO).The ADP5070 is available in a 20-lead LFCSP or in a 20-lead TSSOP and is rated for a −40°C to +125°C junction temperature range.Applications Bipolar amplifiers, ADCs, DACs and multiplexers Charge-coupled device (CCD) bias supply Optical module supply RF power amplifier (PA) bias

Features:

Precision Amplifiers 16V Dual Auto-Zero RRO Precision

LC2MOS 15 V 4 Channel High Performance Analog Multiplexer Features: 44 V supply maximum ratings VSS to VDD analog signal range Low on resistance (100 Ω maximum) Low power (ISUPPLY < 75 µA) Fast switching Break-before-make switching action Plug-in replacement for DG408

3 kV RMS Signal and Power Isolated RS-485 Transceiver with 15 kV IEC ESD Features: 3 kV rms isolated RS-485/RS-422 transceiver Low radiated emissions, integrated, isolated dc-to-dc converter Passes EN 55032 Class B with margin on a 2-layer PCB Cable invert smart feature Correct reversed cable connection on A, B, Y, and Z bus pins while maintaining full receiver fail-safe feature ESD protection on RS-485 A, B, Y and Z pins ≥±12 kV IEC61000-4-2 contact discharge ≥±15 kV IEC61000-4-2 air discharge High speed 25 Mbps data rate (ADM2565E/ADM2567E) Low speed 500 kbps data rate for EMI control (ADM2561E/ADM2563E) Flexible power supplies Input VCC supply of 3 V to 5.5 V Logic VIO supply of 1.7 V to 5.5 V VSEL pin to select VISO supply of 5 V (VCC > 4.5 V) or 3.3 V PROFIBUS compliant for 5 V VISO Wide operating temperature range: −40°C to +105°C High common-mode transient immunity: 250 kV/µs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 196 bus nodes (72 kΩ receiver input impedance) Full hot swap support (glitch free power-up/power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE V 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 Complies with ANSI/TIA/EIA-485-A-98 and ISO 8482:1987(E) 28-lead, fine pitch SOIC_W package (10.15 mm 10.05 mm) with >8.0 mm creepage and clearance
