Demonstration circuit DC2527A-A features the LTM4662EY, a dual 15A or single 30A high efficiency, switch mode step-down power µModule regulator. The input voltage range is from 4.5V to 20V. With CPWR bias, input voltage can be as low as 2.375V. The output voltage range is 0.6V to 5.5V. Derating is necessary for certain VIN, VOUT, frequency and thermal conditions. The DC2527A-A offers the TRACK/SS pin allowing the user to program output tracking or soft-start period. The board operates in continuous conduction mode in heavy load conditions. For high efficiency at low load currents, the MODE_PLLIN jumper can select discontinuous conduction mode. MODE_PLLIN pin also allows the LTM4662 to synchronize to an external clock signal (between 250kHz and 1MHz). DC2527A-A has the option of choosing both internal and external compensation circuit for LTM4662. Tying the PHASMD pin to different pins generates certain phases of CLKOUT and Channel 2. The LTM4662 data sheet must be read in conjunction with this demo manual prior to working on or modifying demo circuit DC2527A-A.

The LTC3864 is a robust, high voltage step-down DC/DC controller optimized for automotive and industrial applications. It drives a P-channel power MOSFET switch allowing 100% duty cycle operation. The wide input and output voltage ranges cover a multitude of applications. This device has been verified with the failure mode and effects analysis (FMEA) procedure for operation during failure conditions.The LTC3864 offers excellent light load efficiency, drawing only 40?A quiescent current in a user programmable Burst Mode operation. Its peak current mode, constant frequency PWM architecture provides for good control of switching frequency and output current limit. The switching frequency can be programmed from 50kHz to 850kHz with an external resistor and can be synchronized to an external clock from 75kHz to 750kHz.The LTC3864 offers programmable soft-start or output tracking. Safety features include overvoltage protection, overcurrent and short-circuit protection including frequency foldback and a power good output signal.The LTC3864 is available in thermally enhanced 12-Pin MSOP and 3mm ? 4mm DFN packages.Applications Industrial and Automotive Power Supplies Telecom Power Supplies Distributed Power Systems

Demonstration circuit 2523A is an 18V, 8.5A (continuous)/12A (peak) synchronous step-down Silent Switcher® with 16µA quiescent current featuring the LT8652S. The LT8652S is a compact, high efficiency, high speed synchronous monolithic step-down switching with the second generation Silent Switcher structure that minimizes EMI and reduces PCB layout sensitivity. Top and bottom power switches, compensation components and other necessary circuits are inside of the LT8652S to minimize external components and simplify design. The demo board has two outputs: 3.3V and 1.2V from a 3.6V to 18V input. The wide input range allows a variety of input sources, such as automotive batteries and industrial supplies. The SYNC pin on the demo board is grounded by default for low ripple Burst Mode® operation. Move JP2 to FCM without SSM position can change the operation mode to forced continuous mode operation. Once JP2 is on FCM with SSM position, VCC is applied to the SYNC pin for low EMI spread spectrum operation. To synchronous to an external clock, move JP2 to SYNC and apply the external clock to the SYNC turret. The demonstration circuit 2523A runs at 2MHz to minimize solution size. The peak efficiency is 90%. The IC temperature rise is less than 70°C when both channels run at full load, 8.5A each, at 2MHz. The demo board has EMI filters installed for both channels. To use the EMI filter, the input should be tied to VEMI1/VEMI2, not VIN1/VIN2. The LT8652S data sheet gives a complete description of the part, operation and application information. The data sheet must be read in conjunction with this demo manual for DC2523A.

The AD8349 is high performance quadrature modulator design for use as a single stage up-converter within wireless infrastructure equipment.The AD8349 provides a high output power and very low noise floor supporting a significant improvement in the output signal range. Additionally the excellent phase and amplitude balance accuracy support a higher sideband suppression specification enabling higher order / capacity QAM modulated radios.The AD8349 has been tested for use over the common Cellular bands (900 MHz, 1.9 GHz, 2.1 GHz) meeting the needs as specified by the CDMA/GSM Edge/W-CDMA standards.The AD8349 is supplied in 16-lead Thin Shrunk Small Outline (TSSOP) package, and fully specified over -40?C to 85?C temperature range.APPLICATIONS Cellular/PCS communication systems infrastructure WCDMA/CDMA2000/PCS/GSM/EDGE Wireless LAN/wireless local loop LMDS/broadband wireless access systemsAVAILABILITYSamples (part number AD8349ARE) and an evaluation board (part number AD8349-EVAL) are available. Other Modulator / Demodulator ProductsAD8345 - 250 - 1000 MHz RF / IF Quadrature ModulatorAD8346 - 2.5 GHz Direct Conversion Quadrature ModulatorAD8347 - 800 MHz to 2.7 GHz RF / IF Quadrature DemodulatorAD8348 - 50 - 1000 MHz RF / IF Quadrature Demodulator

IC MUX 8CH SP JFET DIP16; Multiplexer Configuration:8:1; No. of Circuits:1Circuits; On State Resistance Max:300ohm; Supply Voltage Range:± 15V; Analogue Multiplexer Case:DIP; No. of Pins:16Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:MUX08 Series; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (20-Jun-2016); Analogue Multiplexer Type:8 Channel Single Pole; Analogue Switch Case Style:DIP; Base Number:8; IC Generic Number:08; Logic Function Number:8; No. of Channels:8Channels; On Resistance Rds(on):400ohm; Operating Temperature Range:-40°C to +85°C; Supply Current:15mA; Supply Voltage Source:Dual; Termination Type:Through Hole

3.75 kV, 6-Channel, SPIsolator Digital Isolator for SPI with Delay Clock Features: Supports up to 40 MHz SPI clock speed in delay clock mode Supports up to 17 MHz SPI clock speed in 4-wire mode 4 high speed, low propagation delay, SPI signal isolation channels 2 data channels at 250 kbps Delayed compensation clock line 20-lead SSOP with 5.1 mm creepage High temperature operation: 125°C High common-mode transient immunity: >25 kV/μs Safety and regulatory approvals UL recognition per UL 1577 3750 V rms for 1 minute CSA Component Acceptance Notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 565 V peak

IC CMOS SWITCH DUAL DPDT TSSOP-16; Analogue Switch Type:DPDT; No. of Channels:2Channels; On State Resistance Max:0.4ohm; Supply Voltage Range:4.2V to 5.5V; Analogue Switch Case:TSSOP; No. of Pins:16Pins; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Packaging:Each; Product Range:ADG888 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); Analogue Switch Case Style:TSSOP; Operating Temperature Range:-40°C to +125°C

SWITCH MUX/DEMUX DUAL 2:1 MSOP10; Analogue Switch Type:SPDT; No. of Channels:2Channels; On State Resistance Max:3.45ohm; Supply Voltage Range:1.8V to 5.5V; Analogue Switch Case:MSOP; No. of Pins:10Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:ADG787 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); Analogue Multiplexer Type:USB 1.1 Switch; Analogue Switch Case Style:MSOP; Bandwidth:145MHz; Base Number:787; IC Generic Number:787; Logic Function Number:787; On Resistance Rds(on):2.5ohm; Operating Temperature Range:-40°C to +85°C; Supply Voltage Max:5.5V; Supply Voltage Min:1.8V; Supply Voltage Source:Single; Termination Type:Surface Mount Device; Turn Off Time:3ns; Turn On Time:13ns

MCU 32BIT ARM7TDMI 44MHZ LQFP-40; Product Range:ARM7TDMI Microcontrollers; No. of Bits:32bit; CPU Speed:44MHz; Program Memory Size:62KB; RAM Memory Size:8KB; No. of Pins:40Pins; MCU Case Style:LQFP; No. of I/O's:40I/O's; Architecture:ARM7TDMI; Embedded Interface Type:I2C SPI UART; Supply Voltage Min:2.7V; Supply Voltage Max:3.6V; Packaging:Each; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016); Controller Family/Series:(ARM7) ADuC; EEPROM Memory Size:62KB; IC Generic Number:7026BSTZ62; Logic Function Number:62; MPU Core Size:32bit; Memory Type:Flash; Microprocessor/Controller Features:ARM7TDMI core 16-bit/32-bit RISC architecture/JTAG port supports code download and debug; No. of ADC Inputs:12; No. of PWM Channels:6; No. of Timers:4; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +125°C; Oscillator Type:External Internal; Peripherals:ADC Comparator DAC PLA PSM PWM Timer Temp Sensor; Program Memory Size:62KB

The ADuM1280/ADuM1281/ADuM1285/ADuM1286 are dualchanneldigital isolators based on the Analog Devices, Inc.,iCoupler® technology. Combining high speed CMOS andmonolithic air core transformer technology, these isolationcomponents provide outstanding performance characteristicssuperior to alternatives, such as optocoupler devices and otherintegrated couplers.With propagation delay at 23 ns, pulse width distortion is lessthan 2 ns for C grade. Channel-to-channel matching is tight at5 ns for C grade. The two channels of the ADuM1280/ADuM1281/ADuM1285/ADuM1286 are independent isolation channelsand are available in two channel configurations with threedifferent data rates up to 100 Mbps (see the Ordering Guide).Industrial grade models operate with the supply voltage oneither side ranging from 3.135 V to 5.5 V and the automotivegrades operate from 3.135 V to 5.5 V, providing compatibilitywith lower voltage systems as well as enabling a voltagetranslation functionality across the isolation barrier. Unlikeother optocoupler alternatives, the ADuM1280/ADuM1281/ADuM1285/ADuM1286 isolators have a patented refreshfeature that ensures dc correctness in the absence of input logictransitions. When power is first applied or is not yet applied tothe input side, the ADuM1280 and ADuM1281 have a defaulthigh output, and the ADuM1285 and ADuM1286 have a defaultlow output.For more information on safety and regulatory approvals, go towww.analog.com/iCouplersafety.Applications General-purpose multichannel isolation Data converter isolation Industrial field bus isolation​ Hybrid electric vehicles, battery monitor, and motor drive
